• Range : 9 kHz to 3.0 GHz
• Resolution : Minimum 1 Hz
• Span Range : 100 Hz/div to 300 MHz/div , Selection of 1, 2, 5 steps(automatic), ZERO Span, Full Span ( 9 kHz to 3.0 GHz)
• Frequency Selection : Center Span Setup
• Span Accuracy : +/-3% of the Indicated Span Width
• Readout Accuracy : <= ± (Indicated frequency x Reference frequency accuracy + Span x Span accuracy + 50% of RBW)

• Phase Noise : <=-90dBc/Hz (@ 10kHz offset) + 20 dBm ~ -105dBm, +20dBm ~ -130 dBm (Pre Amp ON)
• Range : +20 dBm ~ -105 dBm
• Average Noise Level (1kHz RBW, 10Hz VBW)

            < = -105 dBm 150 kHz ~ 1 GHz

            < = -135 dBm (Pre Amp On) 20 MHz ~ 1 GHz

            < = -100 dBm, -130 dBm (Pre Amp On) 1 MHz ~ 2.4 GHz

            < = -95 dBm, -120 dBm (Pre Amp On) 2.4 MHz ~ 3 GHz

• Amplitude Unit : dBm, dBmv, dBuV
• Display Scale linearity

             < = ±1.5 dB / 70dB (10dB/div),

             < = ±1.5 dB / 40dB (5dB/div),

             < = ±0.5 dB /   8dB (1dB/div),

              < = ±0.5 dB / 16dB (2dB/div)

• Frequency Response (0 dB attnuation) :

               -3.5 ~ 1.5 dB (100 kHz ~ 10MHz)

                ±1.5 dB (10MHz ~ 3 GHz)

• Reference Level

               Range : -90 dBm to +20 dBm

               Resolution : 0.1 dB steps

               Accuracy : ±1.5 dB

• Second Harmonic Distortion : <= -60 dBc, -40 dBm input
• Inter modulation Distortion : <= -70 dBc, -40 dBm input
• Residual Spurious : <= -85 dBm (Input terminated, 0 dB attenuation)
• Other Input Spurious : <= -60 dBc, -30 dBm input
• Resolution Bandwidth

                Selections : 1kHz , 3kHz , 10kHz, 30kHz, 100kHz, 1 MHz , 3 MHz, 9kHz, 120kHz

                Accuracy : <= ±20%

                Selectivity : 60 dB / 3 dB ratio < 15:1

                                  60 dB / 6 dB ratio < 12 : 1 (9 kHz, 120 kHz)

                 Switching Error :  <= ±1.0 dB (1kHz Reference RBW)

                 Video Bandwidth : 10 Hz to 3 MHz in 1-3-10 steps

• Rate : 100 ms to 1000 sec , 40 ms to 1000 sec (Zero span)
• Accuracy : <= ±20%

• Setup Storage : 20

• Type : PC or Notebook
• Display Resolution : 640(H) x 480 (V) active display area
• Marker Modes : Peak search , Delta marker, Peak Hold , Minhold

• RF Input Connector : N-type female , 50 ohm nominal
• VSWR : 150 kHz to 3.0 GHz, VSWR < 1.5 : 1(with 0 dBm Reference Level)
• Maximum input level : 50 Vdc, +20 dBm

• Temperature Stability : ±0.5 ppm
• Aging : ±0.5 ppm/Year

• RS-232C : Null Modem Remote Control

• Ethernet (Option) : 10-Base-T Ethernet ; Support internet remote control

• System size : Dimensions 436(W) x 88(H) x 485(D) mm
• System Weight : 10 kg
• Warming up Time : 20 minute for the precision measurement
• Input Voltage : 100 ~ 240 VAC at 50/60 Hz
• Power Consumtion : 80 Watt maximum without option
• Operating Temperature : 0 C to 40 C
• Storage Temperature : -20 C to 70 C
